Atala B-Easy SLS 4

B-Easy SLS

Brand

Atala

Electric Kit

Bosch Active Plus Cruise

Colors

White/Dark Red

Size

45 – 50

Mechanical specifications

Frame Alu 700C, hydroformed, easy access, integrated battery, custom tubing, Internal routing, Forged interface
Fork Suntour NEX-E25, 63 mm, Coil, Lockout
Steering FSA No.10, semi-integrated, 1”1/8
Crankset Miranda Epsilon, Miranda 38T
Change Shimano Deore RD-T6000 SGS, Shadow
Commands Shimano Deore SL-T6000 Rapidfire-Plus, 10s
Brakes Shimano BR-MT200, Rotor SM-RT10 180 mm/180 mm
Sprocket set Shimano CS-HG50 10s 11/36
Pedals Alu TKK
Hubs Shimano TX505, CL, 32h
Circles Rodi Tryp25, 25x622, 32h, eBike ready
Handlebar mount Satori UP3e, Internal routing, Bar bore 31,8 mm
Handlebar fold Satori Noirette City, 630 mm
Seat support Satori Harmony, Suspended, 31,6 mm
Seat Selle Royal Lookin
Covers Schwalbe Marathon E-Plus, Smartguard 2.0, Reflex, 700x50
Fenders SKS Evo55 Alu Sandwich
Chain guard SKS Chainbow
Rack Alu, without brackets
External lights F: Trelock Bike-I Airflow 70R: Trelock LS 614, Brakelight
Size 45 – 50
Color White/Dark Red
Note Framelock Axa Victory

Elettrical Specifications

Maximum torque 65 Nm
Sensor type Torque
Battery 500
Battery charger type 4 A
Charger time Up to 4,5 hours
Assisted max speed 25 km/h
Display INTUVIA
Power Eco: 55 %Tour: 120 %Sport: 200 %Turbo: 300 %

Colours, sizes and codes

Geometry


Atala B-Easy SLS geometrie Atala B-Easy SLS geometrie
