Atala B-CROSS AM80 500 4

B-CROSS AM80 500

Brand

Atala

Electric Kit

YAMAHA PW

Colors

Yellow/Black Matt

Size

16” - 18” - 20”

Mechanical specifications

Frame Alu 27,5”, hydroformed, custom tubing, tapered, Internal Routing, Forged interface
Fork Suntour XCM-Coil RL, 100 mm, Remote lockout
Steering FSA No.57BP ZS-1 for 1"1/8 steerer
Crankset Fsa Dyna Drive, chain ring 38T
Change Shimano Altus RD-M2000 SGS
Commands Shimano Altus SL-M2000 Rapidfire, 9s
Brakes Shimano BR-MT200, Rotor SM-RT10 180 mm/180 mm
Sprocket set Shimano CS-HG200 9s 11/36
Pedals Alu MTB
Hubs Shimano TX505, CL, 32h
Circles Rodi Blackrock23, 27,5”, 32h, eBike ready
Handlebar mount Byte Alu Oversize, 60 – 75 – 90 mm
Handlebar fold Byte Alu Low Rise Oversize, 720 mm
Seat support Byte Alu 31,6 mm
Seat Selle Royal Mach
Covers Impac Trailpac 27,5”x2,25”
Size 16” - 18” - 20”
Color Yellow/Black Matt

Elettrical Specifications

Maximum torque 80 Nm
Sensor type Torque
Battery 500
Battery charger type 2 A
Charger time up to 7 hours
Assisted max speed 25 km/h
Display AM LCD
Power Mode 1: 50%Mode 2: 100%Mode 3: 200%Mode 4: 300%Mode 5: 400%

Geometry


Atala B-CROSS AM80 500 geometrie Atala B-CROSS AM80 500 geometrie
