B-Cross A5.4

Specifiche Tecniche

Frame:

Alu 29”, Hydroformed, Integrated battery, Tapered, Internal routing, Forged interface, QR

Fork:

Suntour XCR32, Coil, 29", Travel 100 mm, 1.5 Tapered, QR // Zoom 860 AMS, Coil, Lockout,29", Travel 100 mm, QR, 32mm stanchions

Headset:

Acros for Viper, 1.5”, Internal routing

Crankset:

FSA, 34T, Megatooth

Shifter Levers:

Sram SX Eagle Single Click Trigger, 12s

Rims:

RADIALE E25, eBike Ready, Tubeless Ready, 622x25c

Handlebar:

Alu, 720 mm, Barbore 31.8, Rise 25 mm

Saddle:

Selle Royal Sauris

Mudguards:

Lights

Color:

Anthracite/Black

Rear Derailleur:

Sram SX Eagle

Brakes:

Clarks M4, Rotor SM-RT10 180 mm/180 mm

Cassette:

Sram PG1210 Eagle 12s, 11/50

Pedals:

Alu MTB

Front Hub:

Shimano TX505, CL, 32h

Stem:

Satori Viper 0, Barbore 31.8 mm, Internal routing

Seatpost:

Alu 30,4 mm

Tyres:

Schwalbe Smart Sam, Performance, Addix, 29”x2,35” // Vittoria Barzo 29"x2,25"

Rack:

Sizes:

42 - 46 - 50

Specifiche Elettriche

Battery

EnergyTube 540, frametype

Display

AM LCD

ENGINE

OLI, 36 V, 250 W

Max Power & Torque

250 W

80 Nm

Charger

up to 7 hours

2 A

Autonomy

Max assistance and velocity

25 Km/h

Mode 1: 50% - Mode 2: 100% - Mode 3: 200% - Mode 4: 300% - Mode 5: 400%

Extras
