EXTRAFOLDING 7.1 E

System EcoLogic
EcoLogic FAT/Speed

Black/Anthracite Matt Black/Orange Matt

Telaio	Alu 20” FAT, foldable, integrated battery, integrated HT, disc brake, internal cables
Forcella	Susp 45mm 20”x4", alu crown, whith mechanical lockout
Serie sterzo	FSA integrated 1”1/8
Guarnitura	Alu 170mm, 42T, cartridge
Cambio	Shimano Tourney RD-FT35D
Comandi	Shimano Tourney SL-RS35 RevoShift, 7s
Freni	Hydraulic disk, Rotor 180 mm, with brake lever switch
Ruota Libera	Shimano Tourney 7s 14-28
Pedali	Resin foldable
Mozzi	Alu 36h, axle 135 F/175 R, motor on rear
Cerchi	20" alu, double wall, 36h
Attacco manubrio	Alu, foldable, adjustable
Piega manubrio	Alu, 20mm rise
Reggisella	Alu with clamp, 33,9mm
Sella	Selle Royal Wave
Coperture	20”x4”
Parafanghi	Steel painted
Copricatena	Paracatena
Portapacchi	Alu rear carrier custom, 25kg
Luci esterne	Axa front (30Lux) and rear LED, controlled by display
Taglia	43
Colore	Black/Anthracite Matt Black/Orange Matt
Note	kickstand Ursus adjustable, bell, wheel reflectors

Tipo sensore	Speed sensor w/12 pulses
Batteria	522
Autonomia	Up to 120 km
Tipo caricabatteria	2A Europlug
Tempo di ricarica	100%: 10h14m / 80%: 7h47m
Velocità max assistita	25km/h
Display	LCD
Potenza	5 levels, Speed/Torque adjust
Altre funzioni	Soft start: 0 - 6km/h, with no pedalingExternal light controlSpeed information
