Atala Cult EVO S28 4

Cult EVO S28



Electric Kit

Atala AM80 Agile


Ultralight/Neon Green Matt


45 cm

Mechanical specifications

Frame Alu. Hydroformed 700c, integrated battery, integrated carrier, internal cables
Fork Suntour NEX 700c, alu with alu crown, 50mm
Steering FSA integrted 1”1/8
Crankset AM80 alu crank arm, Miche 38T
Change Shimano Altus RD-M310
Commands Shimano Tourney SL-RS35 RevoShift, 7s
Brakes Shimano BR-MT200 hydraulic disc, Rotor 160 mm INT
Sprocket set Shimano HG200 7s 12-32
Pedals Resin antislip
Hubs Shimano TX505 32h, CL, quick release
Circles Rodi 700c, double wall w/eylets, 32h, disc
Handlebar mount Byte alu over, ahead, adjustable
Handlebar fold Byte aly over, City
Seat support Byte alu with clamp, 27,2mm
Seat Selle Royal Aurorae w/elastomer
Covers Byte Trento 700x38c
Fenders Single stay safety-clip
Chain guard Plastic, L type
Rack Integrated with frame, 25kg load
External lights Axa front (15 lux) and rear LED, controlled by display and twilight sensor
Size 45 cm
Color Ultralight/Neon Green Matt

Elettrical Specifications

Maximum torque 80 Nm
Sensor type Torque
Battery 418
Autonomy level1: up to 140kmlevel2: up to 90kmlevel3: up to 70kmlevel4: up to 65kmlevel5: up to 55km
Battery charger type 2 A
Charger time 100%: 6:30h / 80%: 4h40m
Assisted max speed 25 km/h
Display Atala A10 LCD Smart CAN, with remote control
Power 5 levels, Power adjustlevel1: 50%level2: 100%level3: 150%level4: 200%level5: 250%

Colours, sizes and codes


Atala Cult EVO S28 geometrie Atala Cult EVO S28 geometrie
