Atala B-Rush Plus LTD Gen2 4

B-Rush Plus LTD Gen2



Electric Kit

Bosch Performance CX Cruise


Ultralight/Blue/Green Matt


16” - 17,5” - 19”

Mechanical specifications

Frame Alu 27,5"+, hydroformed, tapered, Rear travel 140 mm, 12x148 mm, Gravity casting interface
Fork Suntour XCR34 LOR, 130 mm, 15x110 mm, Tapered, Lockout
Shock absorber Rock Shox Monarch R, 190x51 mm
Steering FSA No.57E tapered 1"1/2
Crankset FSA Dyna Drive, 14T
Change Shimano Alivio RD-M4000 SGS, Shadow
Commands Shimano Altus SL-M2000 Rapidfire Plus, 9s
Brakes Shimano BR-M315, Rotor SM-RT10 180 mm/180 mm
Sprocket set Shimano CS-HG200 9s 11/36
Pedals Alu MTB Full
Hubs Shimano Deore HB-M6010, 15x110 mm/12x148 mm, CL, 32h
Circles Ambrosio Kono40, 27,5”, 32h, E-Bike ready
Handlebar mount Kyte Alu Oversize, 35 mm
Handlebar fold Kyte Rise Alu Oversize, 780 – 800 mm
Seat support Kyte Alu 31,6 mm
Seat Selle Royal Sauris
Covers Schwalbe Rocket Ron 27,5”x2,80”
Size 16” - 17,5” - 19”
Color Ultralight/Blue/Green Matt

Elettrical Specifications

Maximum torque 75 Nm
Sensor type Torque
Battery 400
Battery charger type 4 A
Charger time Up to 3,5 hours
Assisted max speed 25 km/h
Display PURION
Power Eco: 50 %Tour: 120 %Sport: 210 %Turbo: 300 %

Colours, sizes and codes


Atala B-Rush Plus LTD Gen2 geometrie Atala B-Rush Plus LTD Gen2 geometrie
